What is Fitter good for the Most Important MCQ ITI and CTI,nimi book?



1. Which file is used for manufacturing dies and molds?.

A) Rotary file
B) Tinkers file
C) Barrette file
D) Rasp cut file

ANSWER= (B) Rotary file



2. Which vice is used for holding small work that requires filing or drilling?

A) Pin vice
B) Pipe vice
C) Hand vice
D) Tool maker’s vice

ANSWER= (D) Tool maker’s vice



3. Which hacksaw blade is used for cutting along curved lines?

A) HSS blade
B) All hard blade
C) Flexible blade
D) Diamond blade

ANSWER= (C) Flexible blade



4. Which chisel is used for cutting keyways?

A) Flat chisel
B) Cross cut chisel
C) Punching chisel
D) Diamond point chisel

ANSWER= (B) Cross cut chisel



5. Name the property of metal that withstand shock or impact?

A) Tenacity
B) Hardness
C) Brittleness
D) Toughness

ANSWER= (B) Toughness



6. Which part of the combination set is used to mark and check angles of 90° and 45°?

A) Rule
B) Centre head
C) Squarehead
D) Protractor head

ANSWER= (C) Squarehead



7. 100How much carbon content of steel is forgeable?

A) Up to 1.2 %
B) Up to 1.7 %
C) Up to 1.9 %
D) Up to 2.1 %

ANSWER= (B) Up to 1.7 %



8. What is the use of a try square?

A) To check the right angle
B) To check the acute angle
C) To check obtuse angles
D) To check the straight angle

ANSWER= (A) To check right angle



9. Which part of the universal surface gauge holds the scriber?

A) Snug
B) Guide pin
C) Rocker arm
D) Fine adjustment screw

ANSWER= (A) Snug



10. Why do breakage of teeth occur easily while sawing of thin-walled workpieces and the start of the cut?

A) Hand force is too big
B) Cutting section is too short
C) Coarse blade to be used
D) Hand force acts only upon a few teeth

ANSWER= (D) Hand force acts only upon few teeth



11. What is the spindle movement of one division of thimble with a spindle thread of 0.5mm pitch?

A) 0.01 mm
B) 0.10 mm
C) 1.00 mm
D) 10.0 mm

ANSWER= (A) 0.01 mm



12. What is the use of a feeler gauge? system?

A) Check the width
B) Check the height
C) Check the length
D) Check the gap between the mating parts

ANSWER= (D) Check the gap between the mating parts.



13. What operation is carried out in a gang drilling machine?

A) Idle operation
B) Repeated operation of drilling
C) Continuous milling operation
D) Successive operation of drilling

ANSWER= (D) Successive operation of drilling



14. What is the purpose of slots provided in the slotted angle plate?

A) Job clamping
B) Easy handling
C) Reduce weight
D) Better appearance

ANSWER= (A) Job clamping



15. In the ISO metric thread, calculate the tap drill size for M 10 x 1.5 thread.

A) 8.2 mm
B) 8.7 mm
C) 8.75 mm
D) 8.65 mm

ANSWER= (A) 8.2 mm
